Descrizione
Article features
- Extremely silent cooling: large 120mm fan
- Excellent air flow design for a better heat dissipation
- Full safety design:
- OVP (Over Voltage Protection)
- UVP (Under Voltage Protection)
- SCP (Short Circuit Protection)
- OPP (Over Power Protection)
- Low stand-by consumption
- High energy efficiency: 80+ BRONZE® certified (complies with ErP2014 norm)
- Active-PFC
Technical data
General data
| Peak Power (W) | 750 |
| Form factor ATX 12V | Version 2.4 |
| Voltage (Vac) | 200 – 240 |
| Model | Gaming | XP750R10 |
| Frequency (Hz) | 50 |
| Input current (A) | 10 |
| PFC | active |
| +3.3V (A) | 20 |
| +5V (A) | 20 |
| +12V1 (A) | 62.5 |
| -12V (A) | 0.3 |
| +5Vsb (A) | 3.0 |
| Max. combined power 12V (W) | 750 |
| Max. combined power 3.3V + 5V (W) | 100 |
| +12V2 (A) | – |
Fan / Cooling technology
| Bearing technology | Hydro Bearing |
| Fan size (mm) | 120 |
Protection
| OCP (over current protection) | ✓ |
| OVP (over voltage protection) | ✓ |
| UVP (under voltage protection) | – |
| SCP (short circuit protection) | ✓ |
| OTP (over temperature protection) | – |
| OPP (over power protection) | ✓ |
Eco / Efficiency
| 80PLUS certification | 80+ Bronze |
| Efficiency (%) at 230V, 20% load | >85% |
| Efficiency (%) at 230V, 50% load | >88% |
| Efficiency (%) at 230V, 100% load | >85% |
Environmental directives
| ErP | ✓ |
| WEEE | ✓ |
| RoHS | ✓ |
Cable management / Connectors
| Modular cable management | – |
| Cable length to mainboard (mm) | 500 |
| Cable length to first connector (mm) | 450 |
| Maximum cable length (mm) | 750 |
| Sleeved cables | – |
| No. of cables | 7 |
| ATX-Motherboard (20+4-pin) | 1 |
| P4+4 (CPU) | 2 |
| P8 (CPU) | – |
| PCI-E 6-pin (GPU) | – |
| PCI-E 6+2-pin (GPU) | 4 |
| PATA 4-pin | 3 |
| SATA 15-pin (HDD, Drives) | 8 |
| FDD (Floppy) | – |
Logistics data, RRP
| Range | Gaming |
| Article number | XN235 |
| EAN code | 4044953502361 |
| Dimensions, package (L x W x H), (mm) | – |
| Gross weight, package (kg) | 1.98 |
| Pieces per packaging unit | 8 |
| Dimensions, shipping box (L x W x H), (mm) | 580 x 440 x 265 |
| Gross weight, shipping box (kg) | 16.50 |
E’ consigliabile consultare le informazioni di supporto sul sito del produttore per le specifiche del dispositivo.
